C6 Corvette, All Models, Rear Race Quality Carbon Fiber Rear Wing FC12, 66 inch Wide, Bottom Mounted style

The FC12 wing is our 12" chord single element wing. It can be made any width up to 82".If you would like to make your own uprights and use our airfoil we can put the mounts anywhere you want. Mounts can also be customized to fit your application, just ask.

This profile was designed with efficiency in mind and has a L/D ratio of 7.3. It works exceptionally well at low speeds and high angles of attack for autocross events as well as on road courses where average speeds are 100 mph+.

Pictured is a 72" top mount with a 1/4" gurney flap and large endplates.

Made with 100% carbon fiber on CNC molds that ensure a precise fit, unmatched strength and stiffness as well as being extremely lightweight. You don't want to add weight to your car especially up high like a wing.

All of our wings are made with epoxy infused intermediate modulus carbon fiber @ 60%/40% (dry) fiber to resin content at 1/2 the cost of prepreg with all the stiffness and strength of a 100% carbon fiber wing, including mounts and uprights. No cheap Poly gel coat to peel and chip up.

The mounts pictured are spaced @26.25" so the uprights fit nicely between the tail lights of a C5 and C6 Corvette. No cutting tail light housings or losing the lights function.

The lower uprights are made from solid carbon fiber and bolt directly to the bumper beam for a structural mount. The upper section is also from solid carbon fiber and CNC cut for a precise fit. The 2 part design allows overall height changes to be made without having to pull the bumper cover off every time. Just swap mounts and go.

End plates and uprights included.
