97-2013 Corvette, 10-15 Camaro & Others, Beehive Valve Spring Set 1.055" Top OD; 1.800" Installed Height, .600" Max Lift, Part 9

97-2013 Corvette, 10-15 Camaro & Others, Beehive Valve Spring Set 1.055" Top OD; 1.800" Installed Height, .600" Max Lift, Part 99831-16

This beehive valve spring set features a 1.055" top O.D., an installed height of 1.800" and a maximum lift of .600". A favorite for LS engines with performance hydraulic roller cams.

Number of Springs Per Valve: Single

Outside Diameter of Outer Spring (in): 1.290 in.

Coil Bind Height (in): 1.140 in.

Damper Spring Included: No

Spring Rate (lbs/in): 313 lbs./in.

Inside Diameter of Outer Spring (in): 0.885 in.

Inside Diameter of Inner Spring (in): 0.650 in.

Valve Spring Style: Beehive

Valve Springs Coated: No

Quantity: Sold as a set of 16.

Modern lobe profile.

Ideal for modern and classic muscle, cruisers, street rods and street/strip applications

Grinds that fit a variety of applications: daily drivers to hot street/strip cars.

Ideal for street rods, muscle cars and some street/strip applications, the PowerMax series offers a substantial increase in performance. With a modern lobe profile and a focus on providing more area under the curve, the PowerMax line gives classic and modern cars a sizable power increase without sacrificing durability.

Designed for all-out power.
